Current Position：Home > Product Center > Resistors > SMD Shunt Resistor

SMDShuntResistor

Features:

1  Over current protection

2  Current sense applications

3  Servo motor control circuits

4  Intelligent power modules

 5  Industrial PC moduls and precision measurement system

 6  Current detection circuits in high-speed CPU peripherals



Specification:

1  Resistance value:0.5~100mΩ

2  Tolerance:±1%; ±2%; ±5%

3  Rated Power:2W～10W

 4  Customized special specification size

contact
Product detail
SMD Shunt Resistor, extremely low resistance value allows higher power current sensing with greater efficiency. In addition, the all-metal raised element means lower PCB temperatures due to increased convection under the part. This series is 15~ 30℃ lower than the similar flat chips, providing high accuracy with tolerances down to 1% and TCR as low as 50 PPM for selected resistance values.
